MISUMI HBLTSB5 Thick 90° Bracket, Black — 5 Series, for 2020 Extrusion

Details

MISUMI's compact 90° bracket for the 5 series in black anodised aluminium: 35 × 35 mm legs, 5 mm thick, two Ø5.5 mm holes for M5 screws. Small enough to sit inside a 2020 corner without getting in the way, strong enough for an allowable load of 833 N.

It fits MISUMI HFS5 and any other 20 mm series profile with a 6 mm slot, including 2020, 2040 and 4040. Good for corners and cross-members where you want something tidier than a blind joint, and for mounting plates, skirts or electronics trays to the frame. In black it disappears against a black frame.

• HBLTSB5, black anodised 6061 aluminium
• Price is per bracket, 15 g each
• Screws and T-nuts are not included. Per bracket you need 2× M5×10 socket head screws and 2× M5 T-nuts for a 6 mm slot (MISUMI CBM5-10 and HNTT5-5)
• The photos show the silver HBLTS5; this listing is the black version

Need a heavier bracket? The MISUMI HBKUS5 ultra-thick bracket has 51 mm legs, a rib and slot tabs, in silver or black.

Stock and shipping

Genuine MISUMI parts, in stock in the Netherlands and shipped in 1–2 working days. Add them to a kit or hardware order and they travel in the same parcel.

Need other MISUMI parts, lengths or profiles? Mail me at info@pjotr3dshop.com with the part numbers and I'll quote your order.
